Calculate the Roche limit for Earth, the Moon, a planet or the Sun, or enter your own radius and densities, using the fluid or rigid-body formula.
Calculator Functions
| Function | What it does | What it requires |
|---|---|---|
| Roche limit distance | Finds the distance from a primary body inside which tides can pull a satellite apart | Requires the primary body, the satellite's mean density and the satellite model |
| Satellite density at a limit | Finds the satellite density whose Roche limit falls at a chosen distance | Requires the primary body, the distance from the primary's center and the satellite model |
The primary body can be Earth, the Moon, Mars, Jupiter, Saturn or the Sun, a custom radius and mean density, or a custom central mass in kilograms, Earth masses or solar masses. The satellite model is either the fluid approximation (2.44) or a non-rotating sphere (∛2). Distances can be in kilometers or miles and densities in kg/m³ or g/cm³.
Roche Limit Formulas
| d | Roche limit, measured from the center of the primary |
| C | Model coefficient: 2.44 for a fluid satellite, ∛2 ≈ 1.26 for a non-rotating sphere |
| Rp | Radius of the primary |
| ρp | Mean density of the primary |
| ρs | Mean density of the satellite |
The two coefficients come from two pictures of the satellite. In the simple one the satellite stays a sphere, and the limit is where the primary's tidal pull on the near side matches the satellite's own surface gravity. That distance is (2M ÷ m)1/3 times the satellite's radius, where M and m are the two masses [1], which in terms of density is the main formula with C = ∛2. Treating the satellite as a self-gravitating fluid that stretches under the tide gives the larger coefficient of 2.44 [1].
Roche limit distance
For a satellite with the Moon's density of 3,344 kg/m³ orbiting Earth (radius 6,371 km, mean density 5,513 kg/m³), the fluid model gives 2.44 × 6,371 × (5,513 ÷ 3,344)1/3 = 18,364 km from Earth's center. That is 11,993 km above the surface, or 2.88 Earth radii. The sphere model puts the limit at 9,483 km. Around Saturn, a body of water ice at 917 kg/m³ has a fluid limit of 129,047 km.
Each result also shows the other model's answer, the altitude above the primary's surface and the distance in primary radii. The radius and mean density stored for each listed body agree with NASA's planetary fact sheets to within 1 kg/m³ [3].
With a custom central mass the same limit is written without the primary's radius, where M is the mass of the primary. One Earth mass, 5.9722 × 10²⁴ kg, and a 3,344 kg/m³ satellite give 18,365 km in the fluid model. No altitude is shown, because the size of the primary is not known.
Satellite density at a limit
This is the main formula solved for the satellite's density. At 140,000 km from Saturn's center the fluid model gives 687 × (2.44 × 58,232 ÷ 140,000)3 = 718 kg/m³. A body less dense than that would be inside its own Roche limit at that distance. This figure is known as the Roche critical density, the lowest density at which an orbiting object can hold itself together by its own gravity at a given distance [2].
Limits of This Estimate
- Both models describe a small satellite held together only by its own gravity, orbiting a much more massive spherical primary. Small bodies such as rocks, and even very small moons, can survive inside the limit because their material strength holds them together [1].
- The result is a threshold for an idealized body, not a distance at which breakup is certain. Spin, shape, internal structure and the orbit all shift it, and the two coefficients mark a low and a high case.
- The distance is from the primary's center. A dense satellite can give a limit that lies inside the primary, which means there is no orbit outside the body at which that model predicts breakup.
Sources
- Richard Fitzpatrick, University of Texas at Austin, Celestial Mechanics lecture notes, Roche radius: derivation of the spherical-satellite limit, the 2.44 fluid coefficient and why small bodies survive
- Tiscareno, Hedman, Burns and Castillo-Rogez, Compositions and origins of outer planet systems: Insights from the Roche critical density (2013): meaning of the Roche critical density
- NASA Space Science Data Coordinated Archive, Planetary Fact Sheets: radius, mean density and mass of the Sun, planets and Moon
