Calculate the excess reactant left over from each reactant’s mass, molar mass and coefficient, plus the limiting reactant and percent excess.
Calculator Functions
| Function | What it does | What it requires |
|---|---|---|
| Reaction-based excess | Finds the limiting reactant, the excess reactant and the mass of excess left after the reaction | Requires the mass, molar mass and balanced-equation coefficient of each of two reactants |
| Amount remaining | Finds how much of a reagent is left | Requires the initial amount and the amount consumed |
| Initial amount | Finds how much of a reagent was present at the start | Requires the amount consumed and the amount remaining |
| Amount consumed | Finds how much of a reagent the reaction used | Requires the initial amount and the amount remaining |
Reactant masses are entered in g, kg or mg. Reaction-based excess has optional settings for reactant and product names and for the product’s coefficient and molar mass, which add the theoretical yield. The other three functions use one shared unit, which labels the amounts and does not convert them.
Excess Reagent Formulas
| ER | Excess reagent remaining |
| TR | Initial amount of that reagent |
| U | Amount of that reagent consumed by the reaction |
All three amounts are for the same reagent in the same unit. The amount consumed comes from the balanced equation: the reaction stops when the limiting reagent runs out, and whatever is left of the other reactant is the excess [1]. Reaction-based excess works that out from the masses.
Reaction-based excess
x = smaller of
nA ÷ a and nB ÷ b
left = n − coefficient × x
Each mass is turned into moles, and each mole amount is divided by its coefficient, a or b, from the balanced equation. The reactant with the smaller quotient is the limiting one, and that quotient x sets how far the reaction runs. The moles left of the other reactant are multiplied by its molar mass to give the excess mass. In 4 NH₃ + 5 O₂ → 4 NO + 6 H₂O, 1.70 g of ammonia and 4.00 g of oxygen make 3.00 g of nitrogen oxide, and adding more ammonia makes no more product because the oxygen runs out [1]. With 5.00 g of NH₃ (17.031 g/mol) and 4.00 g of O₂ (31.998 g/mol), n is 0.29358 mol and 0.12501 mol, x is 0.025002 mol, and oxygen is limiting. The reaction uses 1.703 g of ammonia and leaves 3.297 g, or 0.19358 mol. Entering a coefficient of 4 and 30.006 g/mol for NO gives a theoretical yield of 3.001 g.
(nE ÷ e ÷ x − 1) × 100
Percent excess compares the excess reactant supplied, nE moles with coefficient e, with the amount the limiting reactant can use. In the example it is (0.29358 ÷ 4 ÷ 0.025002 − 1) × 100 = 193.56%. When both quotients are equal, the reactants are in exact proportion and nothing is left.
Amount remaining
This is the main formula. Starting with 50 g and consuming 30 g leaves 50 − 30 = 20 g. A consumed amount larger than the initial amount is rejected.
Initial amount
If 30 g were consumed and 20 g remain, the reaction started with 30 + 20 = 50 g.
Amount consumed
Starting with 50 g and ending with 20 g means 50 − 20 = 30 g were consumed.
Limits of This Estimate
- The result is theoretical. It assumes the limiting reactant is used up completely, with no side reactions and no reaction that stops early.
- The coefficients must come from a balanced equation, and both must be from the same equation. A wrong coefficient changes which reactant is limiting.
- Reaction-based excess compares two reactants. A reaction with three or more needs each one checked against the limiting reactant.
Sources
- Purdue University, General Chemistry Topic Review, Chemical Reactions: Mole Ratios and Limiting Reagents: limiting and excess reagents and the ammonia and oxygen example
