Calculate total dB, dB per inch, or total length from any two values, with support for inches, feet, meters, dB/in, dB/ft, and dB/m.
Customize This Calculator
Build your own version. Describe what you want changed, added, or compared.
Related Calculators
- Db Per Decade Calculator
- Leq Noise Calculator
- Efhw Antenna Calculator
- Broadcast Distance Calculator
- All Physics Calculators
Db Per Inch Formula
The calculator uses the relationship between total attenuation, attenuation rate, and length. The base calculation uses inches for length and dB/in for the rate.
To solve for dB per inch:
To solve for total length:
- Total dB is the total gain or loss over the full length, measured in decibels.
- Length is the total distance over which the dB change occurs. The calculator accepts inches, feet, or meters.
- dB/in is the decibel change per inch. The calculator also accepts dB/ft and dB/m, then converts them internally.
If you enter total length and dB per inch, the calculator multiplies them to find total dB. If you enter total dB and length, it divides total dB by length to find the dB per inch. If you enter total dB and dB per inch, it divides total dB by the rate to find the required length.
Length and dB Rate Unit Conversions
These conversions show how the calculator standardizes inputs before solving the missing value.
| Unit | Equivalent in Inches | Use in Calculator |
|---|---|---|
| 1 inch | 1 in | Base length unit |
| 1 foot | 12 in | Converted to inches before calculation |
| 1 meter | 39.3701 in | Converted to inches before calculation |
| Rate Unit | Equivalent dB/in | Example |
|---|---|---|
| dB/in | Same value | 0.5 dB/in = 0.5 dB/in |
| dB/ft | Divide by 12 | 6 dB/ft = 0.5 dB/in |
| dB/m | Divide by 39.3701 | 19.685 dB/m = 0.5 dB/in |
Example Calculations
Example 1: Find total dB
You have a length of 24 inches and a rate of 0.25 dB/in.
The total dB is 6 dB.
Example 2: Find dB per inch
You have a total change of 10 dB over 5 feet.
First convert 5 feet to inches:
Then divide total dB by length:
The rate is 0.1667 dB/in.
FAQ
What does dB per inch mean?
dB per inch means the decibel change for each inch of length. It is commonly used when a signal, sound level, or other measured quantity changes at a steady rate over distance. For example, 0.2 dB/in means the total change increases or decreases by 0.2 dB for every inch.
Can the dB per inch value be negative?
Yes. A negative value can represent loss, reduction, or attenuation over length. A positive value can represent gain or increase. The formula works the same way, but the sign of the result tells you the direction of the change.
Why does the calculator require exactly two values?
The formula has three variables: total length, dB per inch, and total dB. If you know any two of them, the third can be calculated. If fewer than two are entered, there is not enough information. If all three are entered, there is no missing value to solve.
